Design Features  Feeder and transport for processing individual sheets  Basic machine from 1 x MP4 (4 pen) Inkjet printing system  Personalisation, variable data print, e.g. text, numbering, barcodes  High-resolution print systems from 50.8mm to 203.2mm  Optional deep pile feeder and delivery - 650mm height  Additional transport for continuous forms (optional) Basic Machine SV-360 Sheet-fed with MP Inkjet (MultiPen) Controlling Microprocessor Operation Fully automatic Controll desk 7“ Touch display PC Print Controll Windows TM - WYSIWYG Design Editor Transport System Form width Sheet-fed 120mm up to 520mm Form length Sheet-fed 150mm up to 650mm with flat feeder, 750mm with pile feeder Paper weight 70 - 400g/m² sheet-fed (60g/m² with pile feeder) Print System MP (MultiPen 4/8/16) Print width 50.8mm (4 pen), 106.6mmm (8 pen), 203.2.mm (16 pen) Resolution 600x600dpi, 600x300dpi, 300x300dpi Print speed up to 60m/min Standard ink cartridge TIJ 2.5 black water based and solvent based inks as well as different colours avaliable, UV security inks (invisible) Curing oxidative Layout Editor Windows based WYSIWYG layout designer Database-based variable data printing of numbers and texts (Type-True Fonts), graphics, Logos 1D/2D barcodes, datamatrix, QR Code Connections Electrical 1 phase 220-240V, 50/60Hz Connection Dimensions from 2700-4000/800/1500mm (L/D/H) Weight approx. from 300kg, depending on configuration Performace • Performance Single sheets up to 10.000/h

Eas y to M ai n tai n

an d Re tro f i t

The SV-360 sheet-fed system with high resolution MP4 TIJ inkjet printing system finds its perfect use when it comes to variable print personalisation and codings on documents made of paper and cardboard.

Inkjet Printing System with 600dpi

The MP4 inkjet head is installed in a mounting bar and can be moved across machine direction so that any required printing position can be obtained. The well proven TIJ cartridge technology allows high-resolution and accurate imprint of variable data, texts, numbers, barcodes, 2D codes and graphics on a wide variety of single formats from absorbent and non-absorbent substrates. Due to its modular construction, the machine can be extended with increasing demand up to four Inkjet heads. For this, modules with print widths of 50.8mm (4 pen), 101,6mm (8 pen) and 203,2mm (16 pen) are available. An optional paper tractor additionally allows the processing of continuous forms and individual sheets on the same system. WYSIWYG Layout Editor The Windows TM based print control software has an user-friendly layout WYSIWYG editor and takes over the raster image processing of all print data. Variable content such as text, numbering and common 1D / 2D barcodes as well as graphics and logos can simply be placed via drag & drop on the layout and connected directly to the desired database field. Feeding Systems Various feeder and delivery systems are available, tailored to the production volumes. A vacuum rotation feeder unit is used for small to medium press runs, which pulls sheets in formats of up to 520mm x 650mm from below. The magazine capacity is accordingly limited in this case but the feeder can be refilled whilst the machine is running. The processed sheets are delivered into a shaft delivery. The accurately stacked sheets can be removed during operation for further finishing. Autonomous Times Pile feeders and pile delivery systems can be used for large press runs and for long periods of autonomous operation; these are equipped with electrically driven stacker platforms that can be raised and lowered, each with a magazine capacity of 650 mm. Due to their maximum paper format of 520mm x 750mm, these also support the classic B2 sheets. Like the system's upgrade facility, the pile feeder and pile delivery can also be retrofitted at any time. Operating Process After sheet separation with double-sheet inspection, the sheet is drawn to a zero line in the aligning station and passed to the vacuum transport of the printing station. Fixed by the vacuum, the aligned sheet is printed at a constant speed here. After printing the completed sheets are passed to the delivery; during this time a new sheet arrives at the print station ready aligned in order to guarantee continuous production.

Sheet-Fed & Continuous Forms

Design Features  Feeder and transport for processing individual sheets  Basic machine from 1 x MP4 (4 pen) Inkjet printing system  Personalisation, variable data print, e.g. text, numbering, barcodes  High-resolution print systems from 50.8mm to 203.2mm  Optional deep pile feeder and delivery - 650mm height  Additional transport for continuous forms (optional) Basic Machine SV-360 Sheet-fed with MP Inkjet (MultiPen) Controlling Microprocessor Operation Fully automatic Controll desk 7“ Touch display PC Print Controll Windows TM - WYSIWYG Design Editor Transport System Form width Sheet-fed 120mm up to 520mm Form length Sheet-fed 150mm up to 650mm with flat feeder, 750mm with pile feeder Paper weight 70 - 400g/m² sheet-fed (60g/m² with pile feeder) Print System MP (MultiPen 4/8/16) Print width 50.8mm (4 pen), 106.6mmm (8 pen), 203.2.mm (16 pen) Resolution 600x600dpi, 600x300dpi, 300x300dpi Print speed up to 60m/min Standard ink cartridge TIJ 2.5 black water based and solvent based inks as well as different colours avaliable, UV security inks (invisible) Curing oxidative Layout Editor Windows based WYSIWYG layout designer Database-based variable data printing of numbers and texts (Type-True Fonts), graphics, Logos 1D/2D barcodes, datamatrix, QR Code Connections Electrical 1 phase 220-240V, 50/60Hz Connection Dimensions from 2700-4000/800/1500mm (L/D/H) Weight approx. from 300kg, depending on configuration Performace • Performance Single sheets up to 10.000/h

The SV-360 sheet-fed system with high resolution MP4 TIJ inkjet printing system finds its perfect use when it comes to variable print personalisation and codings on documents made of paper and cardboard.

Inkjet Printing System with 600dpi

The MP4 inkjet head is installed in a mounting bar and can be moved across machine direction so that any required printing position can be obtained. The well proven TIJ cartridge technology allows high-resolution and accurate imprint of variable data, texts, numbers, barcodes, 2D codes and graphics on a wide variety of single formats from absorbent and non-absorbent substrates. Due to its modular construction, the machine can be extended with increasing demand up to four Inkjet heads. For this, modules with print widths of 50.8mm (4 pen), 101,6mm (8 pen) and 203,2mm (16 pen) are available. An optional paper tractor additionally allows the processing of continuous forms and individual sheets on the same system. WYSIWYG Layout Editor The Windows TM based print control software has an user-friendly layout WYSIWYG editor and takes over the raster image processing of all print data. Variable content such as text, numbering and common 1D / 2D barcodes as well as graphics and logos can simply be placed via drag & drop on the layout and connected directly to the desired database field. Feeding Systems Various feeder and delivery systems are available, tailored to the production volumes. A vacuum rotation feeder unit is used for small to medium press runs, which pulls sheets in formats of up to 520mm x 650mm from below. The magazine capacity is accordingly limited in this case but the feeder can be refilled whilst the machine is running. The processed sheets are delivered into a shaft delivery. The accurately stacked sheets can be removed during operation for further finishing. Autonomous Times Pile feeders and pile delivery systems can be used for large press runs and for long periods of autonomous operation; these are equipped with electrically driven stacker platforms that can be raised and lowered, each with a magazine capacity of 650 mm. Due to their maximum paper format of 520mm x 750mm, these also support the classic B2 sheets. Like the system's upgrade facility, the pile feeder and pile delivery can also be retrofitted at any time. Operating Process After sheet separation with double-sheet inspection, the sheet is drawn to a zero line in the aligning station and passed to the vacuum transport of the printing station. Fixed by the vacuum, the aligned sheet is printed at a constant speed here. After printing the completed sheets are passed to the delivery; during this time a new sheet arrives at the print station ready aligned in order to guarantee continuous production.

Sheet-Fed & Continuous Forms
