Hologram Applicator / Application Machine

RADUS CFS-610

The base version of CFS-610 hologram applicator with the hologram hot stamping head HP3 covers all requirements in terms of hologram application on pre-printed continuous forms like business forms, computer forms, event tickets, gift vouchers, certificates etc. but also on high-security documents like bank drafts, cheques, visa and other ID related documents. Due to its modular construction, the machine can be extended by retrofitting with increasing demand up to four hologram application heads, also at a later date. This enables the processing of 4 web-lines across simultaneously.

HP3 hot stamping hologram applicator

The HP3 hologram application head contains the stamping press with the replaceable stamping die and the associated fine adjustment as well as the foil feed. In this way, the complete hologram application system can be moved across the paper direction of run in a quick adjustment for positioning. There is no complex conversion of the stamping die or tracking of the foil; jobs can be set-up in shortest time. The hologram embossing unit work electronically / pneumatically and are monitored by the machine's process control. Because of its high flexibility the HP3 is able to apply registered holograms, random pattern holograms and hot foil logos up to a size of 900mm², further each stamping tool can be addressed separately. In addition the powerful HP3 stamping unit is also suitable for applying of scratch-off foils. Print mark recognition with unique „on the fly“ image positioning A multistage tension control in the hologram hot foil track and an accurate guidance guarantee precise hologram feed. To compensate the common hologram foil manufacturing image distance tolerances, the HP3 is equipped with diffraction mark detection directly on the active stamping die to ensure exact image positioning. After mark detection „on the fly“, the foil with the holographic image is positioned using electronics only (Resolution 0.01mm); there is no need for the time consuming manual fine adjustment of the photocells for image positioning. The image position of the hot foil hologram under the stamping die can be easily adjusted via the touch display - even during ongoing stamping operation. Tractor system The tractor system processes fanfold continuous forms up to a width of 23” including sprocket-holes and operates in the base from pack to pack. Depending on the application, the system can be operated via contactless loop switches directly with un- and rewinding units. The processor-controlled system with its two well dimensioned tractors provides a regular paper transport and guidance of the web. The adjustable processing speed of the web allows an individual adaptation to the paper quality. Short distances between tractor system and printing station ensure less paper waste in the machine setup. Operating process By the tractors the web is moved to the work station. Here, one or two HP3 hot stamping hologram heads can be used. The form is stopped under the hologram heads at the required position; stamping then takes place. The operator selects whether one or both heads are used for stamping at the position. After hologram application, the form is moved to the next position. In this way, each form can be stamped in 25 freely- selectable positions, e.g. for tickets, tax labels or cheques arranged one above the other. The completed form is passed to the adjustable delivery. Options If necessary, further work stations can be retrofitted. Here too, one or two HP3 hot-stamping hologram application heads or SU numbering heads can be used. With up to four hologram application heads, even smaller product sizes at forms such as tickets or small tax labels can be processed with up to four lines across the web.
Continuous Forms
© 2024 Arnold Herzig GmbH • Germany - All rights reserved

Smart and Innovative Solutions for the Security Printing Industry

Hologram Applicator /

Application Machine

RADUS CFS-610

Smart and Innovative Solutions - since 1964
Arnold Herzig GmbH
En
De
The base version of CFS-610 hologram applicator with the hologram hot stamping head HP3 covers all requirements in terms of hologram application on pre-printed continuous forms like business forms, computer forms, event tickets, gift vouchers, certificates etc. but also on high-security documents like bank drafts, cheques, visa and other ID related documents. Due to its modular construction, the machine can be extended by retrofitting with increasing demand up to four hologram application heads, also at a later date. This enables the processing of 4 web-lines across simultaneously.

HP3 hot stamping hologram applicator

The HP3 hologram application head contains the stamping press with the replaceable stamping die and the associated fine adjustment as well as the foil feed. In this way, the complete hologram application system can be moved across the paper direction of run in a quick adjustment for positioning. There is no complex conversion of the stamping die or tracking of the foil; jobs can be set-up in shortest time. The hologram embossing unit work electronically / pneumatically and are monitored by the machine's process control. Because of its high flexibility the HP3 is able to apply registered holograms, random pattern holograms and hot foil logos up to a size of 900mm², further each stamping tool can be addressed separately. In addition the powerful HP3 stamping unit is also suitable for applying of scratch-off foils. Print mark recognition with unique „on the fly“ image positioning A multistage tension control in the hologram hot foil track and an accurate guidance guarantee precise hologram feed. To compensate the common hologram foil manufacturing image distance tolerances, the HP3 is equipped with diffraction mark detection directly on the active stamping die to ensure exact image positioning. After mark detection „on the fly“, the foil with the holographic image is positioned using electronics only (Resolution 0.01mm); there is no need for the time consuming manual fine adjustment of the photocells for image positioning. The image position of the hot foil hologram under the stamping die can be easily adjusted via the touch display - even during ongoing stamping operation. Tractor system The tractor system processes fanfold continuous forms up to a width of 23” including sprocket-holes and operates in the base from pack to pack. Depending on the application, the system can be operated via contactless loop switches directly with un- and rewinding units. The processor-controlled system with its two well dimensioned tractors provides a regular paper transport and guidance of the web. The adjustable processing speed of the web allows an individual adaptation to the paper quality. Short distances between tractor system and printing station ensure less paper waste in the machine setup. Operating process By the tractors the web is moved to the work station. Here, one or two HP3 hot stamping hologram heads can be used. The form is stopped under the hologram heads at the required position; stamping then takes place. The operator selects whether one or both heads are used for stamping at the position. After hologram application, the form is moved to the next position. In this way, each form can be stamped in 25 freely- selectable positions, e.g. for tickets, tax labels or cheques arranged one above the other. The completed form is passed to the adjustable delivery. Options If necessary, further work stations can be retrofitted. Here too, one or two HP3 hot-stamping hologram application heads or SU numbering heads can be used. With up to four hologram application heads, even smaller product sizes at forms such as tickets or small tax labels can be processed with up to four lines across the web.
Continuous Forms
SPECIFICATIONS
Functions • Processing of continuous forms with sprocket holes • Processing of web forms without sprocket holes (optional) • Basic system from 1 x hologram applicator HP3 • Expandability up to 4 x hologram applicator HP3 • Expandability with numbering station CFS-601 Basic Model CFS-610 with HP3 Controlling Microprocessor Operation Fully automatic / intermittent Controll desk Display and keyboard Transport System (remaliner pinfeed) Form width 3”-23” incl. sprocket holes cent. adjustment Form length 1/6” - 33” - 1/6”, 1/8”, and 1/10” feed division” Paper weight 40- 200g/m² - form sets up to 400g/m² Transport System (pinless) Form width 50mm - 500mm Form length 10mm - 800mm Resulution 0,1mm Paper weight max. approx. 400g/m² Print mark fork light barrier / print mark reader
HP3 Hologram Applicator Foil size Width 55mm, max. diameter ø 150mm Stamping size 1300mm² max., width max. 50mm Stamping die straightened brass, steel or etched magnesium clichés on brass carriers Temperature 70° bis 250°C Registration mark Optical sensor direct at the hot stamping die Foils Registered security holograms - metallized and demetallized, KINEGRAM®, random pattern holographic foils, scratch foils, hot stamping foils Foil separator Fully automated cutting knife for the separation of the foil and substrate after the stamping operation, can be switched off Connections Air connection 4 – 8 bar, oil-free and dry Electrical con. Single phase 220-240V (110V), 50/60Hz Dimensions Length 1550mm (2300mm with 4 HP3-heads) Depth 1000mm / Height 1500mm Weight approx. 350kg (depending on configuration) Performace Continuous forms 12“ 1up - max. 12.500 holograms/h Continuous forms 3“ 1up - max. 15.000 holograms/h Continuous forms 3“ 4up - max. 60.000 holograms/h
Design Features Processing of continuous forms with sprocket holes Processing of continuous forms (Pinless optional) Basic version from 1 x hologram application head HP3 Expandability up to 8 x hologram application heads HP3 across Stamping size max. ø40mm Expandability with numbering and Inkjet stations Basic Machine CFS-610 HP with Hologram Applicator HP3 Controlling Microprocessor Operation Fully automatic / intermittent Controll desk 7“ Touch display Transport System (remaliner pinfeed) Form width 3”-23” incl. sprocket holes cent. adjustment Form length 1/6” - 33” - 1/6”, 1/8”, and 1/10” feed division” Paper weight 40- 200g/m² - form sets up to 400g/m² Transport System (pinless) Form width 50mm - 500mm Form length 10mm - 800mm Paper weight max. approx. 400g/m² Print mark fork light barrier / print mark reader Hologram Applicator HP3 Foil size Width 55mm, max. diameter ø 150mm Stamping size 1300mm² max., width max. 50mm Stamping die brass, steel or etched magnesium, clichés on brass carriers Temperature 70° bis 250°C Registration mark Optical sensor direct at the hot stamping die Foils Registered security DOVIDs and holograms - metallized and demetallized, KINEGRAM®, random pattern holographic foils, scratch foils, hot stamping foils Foil separator Fully automated foil separation for ensureing a clean result and sharp hologram edges after the stamping / cooling process Connections Air connection 4 – 8 bar, oil-free and dry Electrical con. Single phase 220-240V (110V), 50/60Hz Dimensions Length 1550mm (2300mm with 4 HP3-heads) Depth 1000mm / Height 1500mm Weight approx. 350kg (depending on configuration) Performace • Continuous forms 12“ 1up - max. 12.500 holograms/h • Continuous forms 3“ 1up - max. 15.000 holograms/h • Continuous forms 3“ 4up - max. 60.000 holograms/h
Download Leaflet Video CFS-610  Sales Contact 
